Pyga

Pyga Tig XC Frame

Pyga Tig XC Frame

Regular price R 42,000.00
Regular price Sale price R 42,000.00
Sale Sold out
Tax included.
Size
Color

Please select custom colour to receive more information about all colours available with pricing. Custom builds are also available to suite your needs.

The TIG “ST”as we like to call it, is our Lightweight 120mm frameset tipping the scales at 3.2kg including the Sid-Luxe ultimate rear shock , designed for racing, it can be built up as a sub 11kg bike without breaking the bank. Handcrafted right here in South Africa, from 6066 T6 heat-treated aluminium alloy as used on all our frame models. This alloy has superior properties to 6061 and even higher Tensile strength than 7020 with more elasticity and fatigue resistance.

With its 66deg. head angle and slightly steeper seat angle and 485mm reach (large), the Tig dollar for dollar, will reward you with a super-fast confidence inspiring ride. Its kinematics with a leverage curve at 20% increase gives it exceptional support, anti-rise is between 62% and 74% making for an “active under braking” ride. Anti-squat levels are up at around 140% mid cassette with a 34t front ring providing energy efficient pedalling.

Frameset: 6066 T6 Aluminium, 120mm Travel
Rear Shock: Rockshox SIDLux Trunnion 185×50mm
Rear Axle: 148mm
Seatpost Diameter: 30.9mm
Seat Clamp: DEED 34.9mm
Bottom Bracket: 73mm Threaded
Headset Spec: IS41/IS42
Fork Travel: 120mm
Recommended Axle to Crown: 531mm
Hanger: UDH
Wheel Size: 29″
Max Tire Width: 2.4″
Intended Use: XC/Marathon

Please select custom colour to receive more information about all colours available with pricing. Custom builds are also available to suite your needs.
